Description
310LPH @ 3Bar (13.5V). For flow details at and current draw 13.5V please consult chart below. 044 Equivalent, 60.5mm Pump Diameter, External Check Valve
Pump Chart
Download Pump Charts Flow and Amps PDF
Inlet Options
| AN-6 Adapter | RWF-734-06BK |
| AN-8 Adapter | RWF-734-08BK |
| AN-10 Adapter | RWF-734-10BK |
| AN-12 Adapter | RWF-734-12BK |
| 3/8″ Barb Adapter | RWF-414-M18-06BK |
| 1/2″ Barb Adapter | RWF-414-M18-08BK |
| 5/8″ Barb Adapter | RWF-414-M18-10BK |
| AN-8 Female Swivel Adapter | RWF-906-08-M18BK |
Outlet Options
Using included Check Valve
| AN-6 Banjo Kit | RWF-724-044-06BK |
| AN-8 Banjo Kit | RWF-724-044-08BK |
| 5/16″ Barb Banjo Kit | RWF-807-044-05BK |
| 3/8″ Barb Banjo Kit | RWF-807-044-06BK |
Note: when using the included Check Valve with a banjo kit, outlet will be on a right angle to the pump.
Using a High Flow Inline Check Valve
| AN-6 | RWF-612-06BK |
| AN-8 | RWF-612-08BK |
Using No Check Valve
| AN-6 Adapter | RWF-731-06BK |
| AN-8 Adapter | RWF-731-08BK |
| AN-10 Adapter | RWF-731-10BK |
| 5/16″ Barb Adapter | RWF-414-M12-05BK |
| 3/8″ Barb Adapter | RWF-414-M12-06BK |
| 1/2″ Barb Adapter | RWF-414-M12-08BK |
What is a Check Valve?
A Check Valve, also known as a one-way valve, allows flow in one direction only, and prevents back flow (reverse flow). In the case of a fuel system, this valve ensures that fuel pressure in the line is maintained, allowing the engine to start faster even if the fuel system has not been sufficiently primed.
FLYWHEEL POWER FIGURES (ESTIMATED)
| Normally Aspirated Gasoline | 850HP | 635KW |
| Forced Inducted Low Boost Gasoline | 690HP | 515KW |
| Forced Inducted High Boost Gasoline | 650HP | 485KW |
